3kw Household Small Single Cylinder Electric Start Gasoline Generator
3kw Single Cylinder Electric Start Gasoline Generator
Features:
1. Powerful, stable, durable and reliable.
2. Easy and fast starting, smooth operation and low vibration.
3. Advanced design combustion chamber provides exceptional fuel efficiency and consistent power.
4. Heavy duty frame, unique design of anti vibration and low running temperature prolongs the generator life.
Advantages:
1. Easier to start.
2.Overload protection for safe running
3.Solid Muffler to reduce the noise.
4.Waterproof Protection for the OFF/ON switch.
5.Full frame protection for easy transportation and carry
6.Compact, light and portable power source for entertainment, emergency and home use.
7.Economical, low fuel consumption for continuous stable running .
8.Easy maintenance with brush-less alternator and electronic ignition
9.Standard configuration of voltmeter enables convenient use.
10.AC/DC circuit breaker ensure safety for its overload and shock circuit protection.
11.100% testing with loaded before packing.
12.With CE,GS,ROHS,ISO9001,TUV,SONCAP certification.
13.12 months warranty for long sevices life.
14.Reasonable price with higher quality.
Technical parameters:
| Model No. | KN1200 | KN2500 | KN2800 | KN3000 | KN3500 |
| Engine | Model | HN156FB | HN68FB | HN168FB | HN170F | HN170F |
| Type | Single cylinder, 4-stroke, air-cooled |
| Bore x Stroke | 56x40mm | 70x55mm | 70x55mm | 70x55mm | 70x55mm |
| Displacement | 98cm³ | 212cm³ | 212cm³ | 212cm³ | 212cm³ |
| Max.output power | 3.5/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm | 7.0/3600 Hp/rpm |
| Ignition system | TCL |
| Starting system | Recoil/Electric |
| Fuel tank capacity | 8 liters | 15 liters | 15 liters | 15 liters | 15 liters |
| Continuous operating time | 11 hours | 10 hours | 10 hours | 10 hours | 10 hours |
| Oil capacity | 0.35 liters | 0.6 liters | 0.6 liters | 0.6 liters | 0.6 liters |
| Generator | Rated voltage | 110/220V | 110/220V | 110/220V | 110/220V | 110/220V |
| Rated frequency | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz | 60/50Hz |
| Rated output power | 1000W | 2000W | 2300W | 2500W | 2800W |
| Max.output power | 1100W | 2200W | 2500W | 2800W | 3000W |
| Packing | N.W | 30Kgs | 39Kgs | 41Kgs | 42Kgs | 44Kgs |
| G.W | 31Kgs | 40Kgs | 42Kgs | 43Kgs | 45Kgs |
| Carton size | 50x39x43cm | 61x45x47cm | 61x45x47cm | 61x45x47cm | 61x45x47cm |
| Container Loading | 20’ | 330pcs | 240pcs | 240pcs | 240pcs | 240pcs |
| 40’HQ | 852pcs | 490pcs | 490pcs | 490pcs | 490pcs |
Product pictures:
